TA1017
1700-2400 MHz, 32 W SISO Power Amplifier
The TTRM4710D02 SISO Bi Directional Amplifier is a class AB GaN module with an operating frequency range of 4200 to 4400 MHz. Designed for both military and commercial applications, this amplifier features an input voltage range of +10 to +32 VDC and a saturated RF output power of +46 dBm. With the capability of supporting any signal type and modulation format all in a low SWaP package, this unit is ideal for applications where high power density, efficiency, and linearity are essential.
Lead Time: Call for Quote
Contact Triad RF sales for thermal management options and quantity pricing information
| Model | Frequency Low (MHz) | Frequency High (MHz) | P1dB dBm (Typ) | Tx Gain (dB) | Supply Voltage (Vdc) | Psat (Typ) | Size (in) |
|---|---|---|---|---|---|---|---|
| TA1017 | 1700 | 2400 | 44 | 27 | 10-30 | 45 | 4.925 x 2.533 x 0.7 |
